To solve the problem of shell hole blockage, it is first necessary to clarify the composition and source of the blockage.The grooves and small holes on the surface of the vacuum press roll are used to generate negative pressure during the pressing process, helping dewater the paper web and keep it close to the felt.However, during paper machine operation, fine fibers, fillers (such as calcium carbonate and talcum powder), and sizing agents (such as starch and latex) in the pulp may enter the holes and gradually accumulate over time, resulting in blockage.Such blockage reduces the vacuum effect, lowers dewatering efficiency, and even causes paper quality defects or web breaks.The blockage consists of both organic and inorganic substances. To maintain the good working condition of the vacuum press roll, routine cleaning of the paper machine is generally performed every 7–10 days, especially for black paper production.During cleaning, acidic and alkaline chemicals are sprayed onto the felt, and organic and

Four-roll triple-nip is a commonly used structure in the press section of modern high-speed paper machines, consisting of four press rolls forming three nips. The paper web passes through three consecutive nips to achieve progressive dewatering. The core of the four-roll triple-nip configuration is to use a vacuum press roll to improve dewatering efficiency. Firstly, vacuum suction is applied in the first nip to extract moisture from the interior of the paper web. The web then successively passes through the second and third nips for further mechanical dewatering via roll compression. The main advantages of four-roll triple-nip paper machines are their ability to produce lower-basis-weight paper while operating at high speeds. The shell of a vacuum press roll is drilled with evenly distributed holes or grooves, connected internally to a vacuum system. As the paper web passes through the press nip, the vacuum system inside the roll creates negative pressure, quickly removing moisture from the web and keeping t

The headbox is a core component of the paper machine, which achieves uniform distribution and precise ejection of pulp through the synergistic effect of three parts: the pulp distributor, the weir tank and the slice. Its structure includes components such as a turbulence generator and a dilution water device, which can adjust the pulp flow rate, pressure and fiber dispersion, and directly affect the basis weight distribution and strength properties of paper. It is mainly divided into three types: open type, air-cushion type and hydraulic type.

There are three pulping methods in the pulping process flow: chemical pulping, mechanical pulping, and high-temperature and high-pressure pulping technology. High-temperature and High-pressure Pulping Technology (CTMP)High-temperature and high-pressure pulping technology (CTMP) is an efficient mechanical pulping process. Through the combined action of high temperature, high pressure and chemicals, wood is crushed into fibers, which are then mixed with chemicals to make them suitable for the papermaking industry. The CTMP process flow includes steps such as log pretreatment, cutting, crushing and mixing. Characterized by high efficiency and environmental friendliness, the CTMP process can produce fiberboards with uniform texture and a small amount of wood chips, significantly improving the surface quality and mechanical properties of paper. Chemical PulpingChemical pulping achieves the separation of cellulose from non-cellulosic components such as lignin in wood by using chemical agents, thereby obtaining pure

The cylinder mould paper machine is a common type of papermaking equipment, and its basic structure consists of the following parts: Pulp Supply System: It is responsible for feeding pulp into the headbox of the paper machine, usually conveying the pulp to the next stage via pumps or other conveying devices. Drying Section: Located right after the pressing section, this part is generally composed of multiple layers of drying cylinders. The drying cylinders evaporate the moisture in the pulp through hot air or other heating methods, gradually turning the pulp into paper sheets. Winding Section: The dried paper sheets are wound into paper rolls here, which is typically made up of winding cylinders and a winding device. The winding cylinders rotate to wind up the paper, while the winding device positions and secures the paper roll. In addition, the cylinder mould paper machine is equipped with some auxiliary equipment, such as paper cutters and paper quality inspection devices, which are used for further process
